Product Description
Upgrade your energy independence with the Wall-Mounted 25.6V 314Ah LiFePO4 Lithium Battery. Designed for seamless compatibility with solar and inverter systems, this 8.04kWh storage solution ensures unattended operation, all-around protection, and superior energy efficiency. Built with premium Lithium Iron Phosphate cells, it offers exceptional thermal stability and an industry-leading lifespan of up to 8,000 cycles.
Key Features & Advantages
- Massive Energy Storage: Delivers 8,038.4Wh of nominal energy (25.6V 314Ah) to satisfy heavy-duty residential backup needs.
- Extended Longevity: High-grade cell construction supports up to 8,000 cycles, reducing long-term replacement and maintenance costs.
- Comprehensive BMS Protection: Equipped with built-in safeguards against overcharge, over-discharge, over-current, short-circuit, and over-temperature.
- Smart Communication & Display: Features flexible CAN and RS485 communication interfaces alongside an optional LCD status screen.
- Wall-Mounted Space Saver: Rugged wall-mounted casing designed to optimize floor space while maintaining high durability.
Technical Specifications
| Specification Parameter | Detailed Value |
|---|---|
| Model & Type | 25.6V314AH Wall-Mounted LiFePO4 Battery |
| Nominal Voltage & Capacity | 25.6V / 314Ah (8,038.4Wh) |
| Operation Voltage Range | 20Vdc ~ 29.2Vdc |
| Charge / Discharge Current | Max. Continuous Charge: 100A | Max. Continuous Discharge: 200A |
| Communication & Display | CAN, RS485 (Optional LCD Screen) |
| Dimensions & Weight | 700 × 460 × 160 mm | Net Weight: 57 Kg (Gross: 67 Kg) |
| IP Rating & Operating Temp | IP20 | Working Temp: -10°C ~ +50°C |
Need a Custom Quote or Technical Support?
Connect directly with our sales engineering team via WhatsApp for wholesale pricing and OEM/ODM options.
